Humidity Temperature Vibration Combined Environmental Chamber For Car Battery Testing
DGBELL 15+ years experience in test chambers manufacturing, High performance for your projects.
Applications
The combined temperature and humidity vibration test chamber conforms to national standards and meets specific testing requirements. Through the combination of high and low temperature, low temperature, temperature change, shock, damp heat vibration and other environmental reliability tests, it is widely used for electronic and electrical products, automotive parts, materials, etc.
Features
1. High-precision perfect shape design, external use of double-sided cold-rolled plate electrostatic powder coating material, internal use of SUS# 304 high-temperature resistant stainless steel.
2. Insulation material adopts refractory high-strength PU polyurethane foam insulation material.
3. Advanced refrigerator control technology from Japan and Germany is introduced to save more than 20% energy.
4. Control system and control circuit components are adopted from famous brands.
Standard Compliance
IEC 68-2-1 (GB2423.1-2008)
IEC 68-2-2 (GB2423.2-2008)
IEC 68-2-3 (GB2423.3-2006)
IEC 68-2-30 (GB2423.4-2008)
IEC 68-2-14 (GB2423.22-2008)
MIL-STD-810D (GJB150.3A-2009)
MIL-STD-810D (GJB150.4A-2009)
MIL-STD-810D (GJB150.9A-2009)
Performance parameters
| Model | BTHZ-408 | BTHZ-800 | BTHZ-1000 |
| Internal Dimension W x H x D(mm) | 600x850x800 | 1000x1000x800 | 1000x1000x1000 |
| External Dimension W x H x D(mm) | 850x1650x1500 | 1250x1750x1600 | 1250x1750x1800 |
| Temp. Range | B:-20～150℃ C:-40～150℃ D:-70～150℃ |
| Humidity Range | 20-98%RH |
| Temp. Fluctuation | ≤±0.5℃ |
| Temp. Deviation | ≤±2℃ |
| Temp. Uniformity | ≤±2℃ |
| Humidity Fluctuation | ≤±2.5%RH |
| Humidity Deviation | Temperature 75%RH: ≤+2,-3%RH |
FAQ
Q1 : Can you customize the product?
A: Yes, we can customize any products according to requirements. Hot selling lab electronic
temperature humidity cabinet/Environmental climate test chamber/Car Battery Safety Test Chamber also can be customized.
Q2 : How to choose the most suitable products?
A: Our professional team will give you the best suggestion, just be patiently to tell us the information
about the parameters you require.
Q3 : Can you arrange installations and commissioning in our lab?
A: Firstly, for standard chamber we had 3-5 days commissioning before shipping,
you just need link power in your lab, then you can start to operate.
Secondly, we had detailed operation manual with chamber , any problems you can find and solve in it.
Thirdly, some customized chambers we should install and teach your team to operate .
